textile loom motors

Textile Loom Motor Manufacturer | Bhavani Motors Bhavani Textile Loom Motors are standard AC induction motors selected and configured for textile-loom applications. Single Phase and Three Phase models are available with different power ratings, speeds and mounting options according to loom-machine requirements. These motors are manufactured with 100% copper winding and are available in aluminium and cast-iron bodies. Custom voltage, frequency, shaft, flange and duty-cycle options can be provided according to the application. Bhavani supplies the electric motor only. Textile loom machines, pulleys, couplings and complete drive assemblies are not included. Technical Specifications Single Phase • Power Range: 0.25–5 HP • Speed Options: 1440 and 2880 RPM • Standard Voltage: 220–240V • Standard Frequency: 50Hz • Custom Voltage/Frequency: Available • IEC Frame Range: IEC 63–132S • Capacitor: Dual capacitor — Start and Run Three Phase • Power Range: 0.25–75 HP • Speed Options: 720, 960, 1440 and 2880 RPM • Standard Voltage: 415V • Standard Frequency: 50Hz • Custom Voltage/Frequency: Available • IEC Frame Range: IEC 63–250M • Capacitor: Not applicable Common Specifications • Product Type: AC Induction Motor for Textile Loom • Supply Scope: Electric motor only • Mounting Options: B3, B5, B35, B14 and B34 • Aluminium Body Range: 0.25–3 HP • Cast-Iron Body Range: According to selected phase and power • Enclosure: TEFC standard • TENV Construction: Available on request for applicable models • IP Protection: IP44/IP55 available • Duty: S1 standard; S2/S3/S4 on request • Insulation: Class F standard; Class H on request • Winding: 100% Copper Winding • Warranty: 12 months against manufacturing defects Mounting Options • B3: Foot Mounted • B5: Full Flange • B35: Foot Cum Full Flange • B14: Face Flange • B34: Foot Cum Face Flange Mounting availability must be confirmed according to the selected motor power, body material and IEC frame size. Key Features • Suitable for textile-loom applications • Single Phase and Three Phase models • Multiple power and RPM options • 100% copper winding • Aluminium and cast-iron body options • TEFC enclosed construction • Multiple IEC mounting options • Custom voltage and frequency available • Special shaft and flange available • VFD-compatible Three Phase winding available on request • 12-month warranty against manufacturing defects Application Bhavani Textile Loom Motors are designed for integration into: • Textile loom machines Final motor selection must be based on the loom type, required RPM, load, starting requirement, duty cycle and mounting arrangement. Customization Options • Special shaft dimensions • Double or extended shaft • Custom flange dimensions and PCD • Custom voltage and frequency • VFD-compatible winding for Three Phase models • Special duty cycle • Class H insulation Information Required for Selection Customers should provide: • Loom-machine application • Required motor HP • Single Phase or Three Phase • Required RPM • Voltage and frequency • Mounting type • Shaft dimensions • Flange drawing, if applicable • Duty cycle • Starting and load requirements • VFD operation details, if applicable Important Supply Note Bhavani manufactures and supplies the electric motor only. Textile loom machinery, pulley, coupling, belt and complete drive assembly are outside the standard supply scope.
