Blower Duty Motors Manufacturer in Ahmedabad, Gujarat, India. Bhavani Blower Duty Motors are 2-pole AC induction motors designed for industrial blower, ventilation and process-air applications. These motors operate at approximately 2880 RPM on 50Hz supply and approximately 3450 RPM on 60Hz supply. Single Phase Blower Motors are available from 0.25 HP to 5 HP, while Three Phase Blower Motors are available from 0.25 HP to 75 HP. Multiple mounting, body-material and customization options are available to suit different blower designs. Bhavani supplies the electric motor only. Blower impellers, housings and complete blower assemblies are not included. Technical Specifications Single Phase • Power Range: 0.25–5 HP • Voltage: 220–240V • Frequency: 50Hz/60Hz • Speed at 50Hz: Approximately 2880 RPM • Speed at 60Hz: Approximately 3450 RPM • IEC Frame Range: IEC 63–132S • Capacitor Configuration: According to HP/application Three Phase • Power Range: 0.25–75 HP • Voltage: 415V • Frequency: 50Hz/60Hz • Speed at 50Hz: Approximately 2880 RPM • Speed at 60Hz: Approximately 3450 RPM • IEC Frame Range: IEC 63–250M • Capacitor Configuration: Not applicable Common Specifications • Product Type: 2 Pole Blower Duty Induction Motor • Supply Scope: Electric motor only • Mounting Options: B3, B5, B35, B14 and B34 • Aluminium Body Range: 0.25–3 HP • Cast-Iron Body Range: 0.25–75 HP • Enclosure: TEFC standard; TENV on request • IP Protection: IP44/IP55 available • Duty: S1 standard; S2/S3/S4 on request • Insulation: Class F standard; Class H on request • Winding: 100% Copper Winding • Warranty: 12 months against manufacturing defects Key Features • Designed for industrial blower applications • 2880 RPM operation at 50Hz • Approximately 3450 RPM at 60Hz • Single Phase and Three Phase options • 100% copper winding • Aluminium and cast-iron body options • TEFC enclosure as standard • Multiple mounting configurations • Special shaft and flange customization • VFD-compatible winding available on request • 12-month warranty against manufacturing defects Applications Bhavani Blower Duty Motors can be selected for: • Centrifugal blowers • Industrial air blowers • Dust-collection blowers • Exhaust and ventilation fans • Process-air systems Final motor selection must be based on the blower load, required airflow, static pressure, impeller characteristics and operating conditions. Customization Options • Special shaft dimensions • Double or extended shaft • Custom flange dimensions and PCD • Custom voltage and frequency • VFD-compatible winding • Special duty cycle • Class H insulation • TENV construction Information Required for Motor Selection Customers should provide: • Required motor HP • Single Phase or Three Phase • Required voltage and frequency • Blower type • Required operating RPM • Mounting requirement • Impeller details • Shaft dimensions • Duty cycle • Direct-coupled or belt-driven arrangement • Application and operating conditions Important Supply Note Bhavani Induction Motors manufactures and supplies the electric motor only. The blower impeller, blower casing, fan and complete blower assembly are outside the standard supply scope.
